Project Description

GK 125-H(125cc,*Reverse*)

Engine Type: 125CC, 4 Stroke, Single Cylinder

Transmission: Automatic With Reverse, D+N+R

Cooling System: Air-cooled

Ignition: CDI

Starting System: Electric Start

Battery: 12V, 5Ah

Final Drive: Chain Drive, Rear Wheel Drive

F/R Brakes: Hydraulic Disc (foot)

Max Speed: 30-35MPH

Fuel Capacity: 7L

Front/Rear Tire: 16/8.00-7

Max Horsepower: 4.7KW/8000R/Min

Max torque: 6.9/6500±500 (N. m/r/min)

Max load: 180LBS

Weight: G.W:413LBS/N.W:368 LBS

Dimensions Wheelbase: 1310mm

Carton Dimensions: L*W*H: 70” x 44”x 24”

Ground Clearance: 170mm

Colors: Red, Blue, Black, Green, Pink
